When selecting the Manual option on the Surface Contact form, the following sections are available:
It allows you to define manual contact with different options by selecting Master and Slave entities. MSC Nastran Quick Reference Guide) A margin of safety is also output when the stresses are real. Figure 8-68 CSHEAR Shear Panel Corner Forces and Shear Flows (Ref. The average of the four corner stresses and the maximum stress are output on request in either the real or complex form. The shear stresses are calculated at the corners in skewed coordinates parallel to the exterior edges. These forces consist of the forces applied to the element at the corners in the direction of the sides, kick forces at the corners in a direction normal to the plane formed by the two adjacent edges, and shear flows (force per unit length) along the four edges. MSC Nastran Quick Reference Guide) The positive directions for these forces are indicated in Figure 8-68. The element forces are output on request in either real or complex form.įigure 8-67 Shear Panel Connection and Coordinate System (Ref. The labels G1, G2, G3, and G4 refer to the order of the connected grid points on the CSHEAR entry. The element coordinate system for a shear panel is shown in Figure 8-67. Dodge Caravan 2018 Sxt Plus Manual here.ĭetails of the shear panel element are discussed in Section 3.0 of The MSC NASTRAN Theoretical Manual. The structural and nonstructural mass of the shear panel is lumped at the connected grid points.
#Nx nastran reference manual how to#
If they are in lb, then how to get the shear flow from these numbers in lb/in? A shear panel is a two-dimensional structural element that resists the action of tangential forces applied to its edges, and the action of normal forces if effectiveness factors are used on the alternate form of the PSHEAR Bulk Data entry. In the force output (bold) for the CSHEAR sample element below, what are the units of the SHEAR-XX quantities, is it lb/in or lb? Per page 897/913 in the NX Nastran quick reference guide, they seem to be lb. Refer to Autodesk Nastran Reference Manual for more information. When selecting the Manual option on the Surface Contact form. MSC Nastran 2004 Reference Manual describes uses of File managament, Executive Control, Case Control, Parameters and Bulk Data entries in Nastran.
#Nx nastran reference manual manuals#
NX Nastran 8.1 Quick Reference Guide NX Nastran 8.1 Release Guide NX Nastran 8.0 Platform Support Guide NX Nastran 8.0 Product Manuals NX Nastran 7.1 Advanced Nonlinear Theory and Modeling Guide NX Nastran 7.1 DMAP Programmer's Guide NX Nastran 7.1 Quick Reference Guide. Tell us about your issue and find the best support option. Nastran Quick Reference Manual Average ratng: 7,3/10 2621votes
